| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | SPRING | S.S.304 |
| 3 | BOARD | BRASS |
| 4 | WASHER | NBR |
| 5 | CAP | ABS |
| 6 | NET | S.S.304 |
| 7 | CAP | S.S.304 |
| Size Inch | Working Bar | Pressure Psi | Max. Working Temperature |
|---|---|---|---|
| 1/2" | 20 | 300 | -20° to 90° |
| 3/4" | 20 | 300 | -20° to 90° |
| 1" | 20 | 300 | -20° to 90° |
| 1.1/4" | 20 | 300 | -20° to 90° |
| 1.1/2" | 20 | 300 | -20° to 90° |
| 2" | 20 | 300 | -20° to 90° |
| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" |
|---|---|---|---|---|---|---|
| A | 69 | 80.5 | 96 | 111 | 127.5 | 145 |
| B | 32.5 | 41.5 | 47 | 58 | 67.5 | 80 |
